1. Product Feature
uDual mandatory 100M full-duplex Ethernet interface, 2KV electromagnetic isolation, default configuration is MDI mode;
uEthernet using "D" encoding M12 connector;
uThe working mode of Ethernet can be selected as TCP Server, TCP Client, UDP and UDP multicast. The working port, target IP and port can be set.
uEthernet application layer protocol conforms to the standard of both IEC61375-2-3 and IEC61375-3-4, and supports TRDP protocol.
uEthernet supports static or dynamic IP.
uMAC address is globally unique or configurable.
uEthernet supports TCN-DNS and TTDB;
uIntegrated 1/2 of CAN2.0B interface, compatible with CAN2.0A, and complies with ISO11898-1 standard;
uThe CAN baud rate is 40K~1Mbps, and the default baud rate is 250Kbps.
uCAN interface electrical isolation: DC 2500V or AC 1700V;
uThe CAN interface is equipped with the standard CANOpen DB9 interface, which conforms to the IEC61375-3-3 standard.
uIntegrated with one 3-wire RS-232 communication interface or one 2-wire RS-485 communication interface, the default communication rate is 115200bps, other baud rate requirements can be customized;
uRS232/485 circuit uses DC 2500V electrical isolation;
uMain power supply adopts 9-36V wide voltage DC isolation power supply, isolation withstand voltage 1500VDC;
uOperating temperature: -40℃ ~ +85℃
uStorage temperature: -40℃ ~ +85℃
uMax relative humidity: 90%
