1. Feature
uWireless standard: Bluetooth 5.0（Bluetooth ® 5.0,ANT）, AES HW Encryption security function;
uBluetooth frequency: 2400MHz-- 2483.5MHz, GFSK Modulation technology;
uBluetooth transmission rate: Uncoded: 1 Mbps / 2 Mbps, Coded: 125 kbps (S = 8) / 500kbps (S = 2);
uBluetooth working mode: Central/Peripheral, Bluetooth master can be connected by 9 slaves;
uBluetooth MAC address is globally unique.
uBluetooth transmission power: -20 ~ +4 dBm configurable;
uBluetooth supports name connection, MAC connection and maximum signal connection.
uIntegrated 1 CAN2.0B interface, compatible with CAN2.0A, complies with ISO11898-1 standards;
uThe CAN baud rate is 40K~1Mbps, and the default baud rate is 250Kbps.
uCAN interface electrical isolation: DC 2500V or AC 1700V;
uCAN interface is equipped with standard OPEN terminal;
uOne RS232 is provided as the parameter configuration port, and the baud rate is fixed to 115200bps.
uMain power supply adopts 9-36V wide voltage DC isolation power supply, isolation withstand voltage 1500VDC;
uOperating temperature: -40℃ ~ +85℃
uStorage temperature: -40℃ ~ +85℃
uMax relative humidity: 90%
2. Normative Reference
uEMC meets the requirements of EN 50121-3-2:2006;
uCAN conforms to the latest standard ISO11898-1.
3. Interface
It has 1 Bluetooth , 1 CAN interface and 1 power interface.
